Quail Monitor

1#include <LiquidCrystal.h>
2#include <Adafruit_NeoPixel.h>
3// C++ code
4//
5
6// LCD Constants
7const int RS  = 2;
8const int E   = 3;
9const int DB4 = 4;
10const int DB5 = 5;
11const int DB6 = 6;
12const int DB7 = 7;
13const int DC_MOTOR = 9;
14
15// DC MOTOR Constants
16const int OFF_SPEED = 0;
17const int LOW_SPEED = 64;
18const int MED_SPEED = 128;
19const int HIGH_SPEED = 255;
20
21// Thresholds
22const int TEMP_LOW_THRESHOLD = 65;
23const int TEMP_HIGH_THRESHOLD = 80;
24const int FAN_LOW_THRESHOLD = 80;
25const int FAN_MED_THRESHOLD = 90;
26const int FAN_HIGH_THRESHOLD = 100;
27const int WATER_LOW_THRESHOLD = 300;
28
29// Create LCD object
30LiquidCrystal lcd(RS, E, DB4, DB5, DB6, DB7);
31
32// Soil moisture sensor
33const int MOISTURE_SENSOR = A0;
34
35// TMP36 temperature sensor
36const int TEMP_SENSOR = A1;
37
38// NeoPixel PIN
39const int PIXEL_PIN = 8;
40
41// Pixel Count
42const int PIXEL_COUNT = 32;
43
44
45// Create NeoPixel strip object
46Adafruit_NeoPixel strip(
47  PIXEL_COUNT,
48  PIXEL_PIN,
49  NEO_GRB + NEO_KHZ800
50);
51
52// Colors
53const uint32_t RED = strip.Color(255, 0, 0);
54const uint32_t GREEN = strip.Color(0, 255, 0);
55const uint32_t OFF = strip.Color(0, 0, 0);
56
57// Variables
58int moistureValue = 0;
59int tempSensorValue = 0;
60int tempC = 0;
61int tempF = 0;
62
63
64void setup()
65{
66  // Temp Sensor
67  pinMode(TEMP_SENSOR, INPUT);
68  Serial.begin(9600);
69
70  // Initialize LCD
71  lcd.begin(16, 2);
72
73  // Initialize NeoPixels
74  strip.begin();
75  strip.show();
76
77  // DC_MOTOR
78  pinMode(DC_MOTOR, OUTPUT);
79
80  // Startup message
81  lcd.setCursor(0, 0);
82  lcd.print("Quail Monitor");
83  delay(1500);
84}
85
86void loop()
87{
88  // Read the sensor value (analog)
89  tempSensorValue = analogRead(TEMP_SENSOR);
90
91  // Map sensor value (20 to 358) to celsius temp (-40 to 125)
92  tempC = map(tempSensorValue, 20, 358, -40, 125);
93
94  // Calculate the temp in Fahrenheit
95  tempF = 9 * tempC / 5 + 32;
96  Serial.print("Temp Value: ");
97  Serial.println(tempF);
98
99  // Read moisture sensor
100  moistureValue = analogRead(MOISTURE_SENSOR);
101  Serial.print("Moisture Value: ");
102  Serial.println(moistureValue);
103
104  // Determine warning states
105  bool tempLow = tempF < TEMP_LOW_THRESHOLD;
106  bool tempHigh = tempF >= TEMP_HIGH_THRESHOLD;
107  bool waterLow = moistureValue < WATER_LOW_THRESHOLD;
108
109  // Determine overall system status
110  bool systemSafe = !tempLow && !tempHigh && !waterLow;
111
112  // Updating NeoPixel to reflect status
113  if (systemSafe) {
114    setNeoColor(GREEN);
115  }
116  else {
117    setNeoColor(RED);
118  }
119
120  // Update fan speed
121  updateFanSpeed();
122
123  // Always show temperature first
124  showTemperature();
125  delay(2000);
126
127  // Rotate warning messages
128  if (tempLow) {
129    showWarning("TEMP LOW");
130    delay(2000);
131  }
132
133  if (tempHigh) {
134    showWarning("TEMP HIGH");
135    delay(2000);
136  }
137
138  if (waterLow) {
139    showWarning("WATER LOW");
140    delay(2000);
141  }
142
143  // If safe, show SAFE message
144  if (systemSafe) {
145    showSafe();
146    delay(2000);
147  }
148
149}
150
151// Helper functions
152void setNeoColor(uint32_t color){
153  for (int i = 0; i < PIXEL_COUNT; i++) {
154    strip.setPixelColor(i, color);
155  }
156  strip.show();
157}
158
159void showTemperature() {
160  clearLCDRows();
161  lcd.setCursor(0, 0);
162  lcd.print("Temperature:");
163  lcd.setCursor(0, 1);
164  lcd.print(tempF);
165  lcd.print(" F");
166}
167
168void showWarning(String message) {
169  clearLCDRows();
170  lcd.setCursor(0, 0);
171  lcd.print("WARNING:");
172  lcd.setCursor(0, 1);
173  lcd.print(message);
174}
175
176void showSafe() {
177  clearLCDRows();
178  lcd.setCursor(0, 0);
179  lcd.print("System Status");
180  lcd.setCursor(0, 1);
181  lcd.print("ALL GOOD");
182}
183
184void clearLCDRows() {
185  lcd.setCursor(0, 0);
186  lcd.print("                ");
187  lcd.setCursor(0, 1);
188  lcd.print("                ");
189}
190
191void updateFanSpeed() {
192  if (tempF >= FAN_HIGH_THRESHOLD) {
193    // Very hot
194    analogWrite(DC_MOTOR, HIGH_SPEED);
195  }
196  else if (tempF >= FAN_MED_THRESHOLD) {
197    // Hot
198    analogWrite(DC_MOTOR, MED_SPEED);
199  }
200  else if (tempF >= FAN_LOW_THRESHOLD) {
201	// Warm
202    analogWrite(DC_MOTOR, LOW_SPEED);
203  }
204  else {
205	// Safe
206    analogWrite(DC_MOTOR, OFF_SPEED);
207  }
208}
